Chemical Mixing Tanks

Chemical Mixing Tanks, Built to Endure

Our priority is to provide a safe, secure and sanitary solution for all your chemical mixing and tank storage needs. Our mixing tanks are designed for long term storage and are built to last.

All Novid chemical mixing tanks are environmentally friendly and manufactured using corrosive resistant 304L or 316L stainless steel.

Stainless Steel eliminates the need for repairs or paint touch ups and has the potential to last indefinitely.

Safe storage & mixing of chemicals always includes a combination of following best practices and using the best/most cost effective storage systems.

Novid is CWB Division 2 certified, and we understand the importance of using accurate and superior welding procedures and processes in order to deliver the best product.

Stamped engineered drawings for site specific requirements are available upon request.

Testimony

“Harvest Land purchased 4 X 30,000 US gallon flat bottom tanks from Novid in 2014 along with 10 chemical tanks. We’re proud to have the 30,000 gallon tanks displayed in the front of our Springfield, Minnesota location. Novid’s commitment to providing high quality tanks, on time delivery, and great after sale service is second to none. I would definitely recommend Novid to anyone who is looking for long term fertilizer storage.”

Scott Arnsdorf– Plant Manager, Harvest Land Cooperative, Springfield Minnesota

Specs

Chemical Mixing Tank Features

Butt Welded Joints
18” Top Manway
2 Lifting Lugs
2x 2” Couplers
2” Bottom Discharge and Pipe
Roof Vent
Eductors standard (Poly)

Options

Air Mixing with DAS (Diffuser Aeration System)
SS Ladder/Cage
3” or 4″ Fittings
Flange Fittings
3/4″ Sight Tube
Stainless Steel Eductor Upgrade
Pressure Vacuum Vent
Custom Designs
Manufactured for Potable Water Storage

Mix Tank featuring DAS (Diffuser Aeration System)

Photos

Chemical Mixing Tank Sizes

6' Diameter

Height

US gal

Imp gal

Overall Height

883

735

6.3'

1,094

911

7.3'

1,728

1,439

10.3'

1,940

1,615

11.3'

10'

2,151

1,791

12.3'

12'

2,574

2,143

14.3'

13'

2,785

2,319

14.3'

14'

2,997

2,495

16.3'

15'

3,208

2,671

17.3'

16'

3,420

2,847

18.3'

17'

3,631

3,023

19.3'

18'

3,842

3,200

20.3'

19'

4,054

3,376

21.3'

20'

4,265

3,552

22.3'

7' Diameter

Height

US gal

Imp gal

Overall Height

1,210

1,008

6.5'

1,498

1,247

7.5'

2,361

1,966

10.5'

2,649

2,206

11.5'

10'

2,937

2,445

12.5'

12'

3,512

2,924

14.5'

13'

3,800

3,164

15.5'

14'

4,088

3,404

16.5'

15'

4,375

3,643

17.5'

16'

4,663

3,883

18.5'

17'

4,951

4,122

19.5'

18'

5,238

4,362

20.5'

19'

5,526

4,841

22.5'

20'

5,814

4,841

22.5'

8' Diameter

Height

US gal

Imp gal

Overall Height

1,592

1,325

6.7'

1,967

1,638

7.7'

3,095

2,577

10.7'

3,471

2,890

11.7'

10'

3,847

3,203

12.7'

12'

4,598

3,829

14.7'

13'

4,974

4,142

15.7'

14'

5,350

4,455

16.7'

15'

5,726

4,768

17.7'

16'

6,101

5,081

18.7'

17'

6,477

5,393

19.7'

18'

6,853

5,706

20.7'

19'

7,229

6,019

21.7'

20'

7,605

6,332

22.7'

21'

7,981

6,645

23.7'

22'

8,356

6,958

24.7'

23'

8,732

7,271

25.7'

24'

9,108

7,584

26.7'

25'

9,484

7,897

27.7'

9' Diameter

Height

US gal

Imp gal

Overall Height

2,028

1,689

6.9'

2,504

2,085

7.9'

3,931

3,273

10.9'

4,407

3,669

11.9'

10'

4,882

4,065

12.9'

12'

5,834

4,857

14.9'

13'

6,309

5,254

15.9'

14'

6,785

5,650

16.9'

15'

7,261

6,046

17.9'

16'

7,736

6,442

18.9'

17'

8,212

6,838

19.9'

18'

8,687

7,234

20.9'

19'

9,163

7,630

21.9'

20'

9,639

8,026

22.9'

21'

10,114

8,422

23.9'

22'

10,590

8,818

24.9'

23'

11,066

9,214

25.9'

24'

11,541

9,610

26.9'

25'

12,017

10,006

27.9'

10' Diameter

Height

US gal

Imp gal

Overall Height

2,705

2,252

8.0'

3,292

2,741

9.0'

5,054

4,208

12.0'

5,641

2,697

13.0'

10'

6,228

5,186

14.0'

12'

7,403

6,164

16.0'

13'

7,990

6,653

17.0'

14'

8,577

7,142

18.0'

15'

9,165

7,631

19.0'

16'

9,752

8,120

20.0'

17'

10,339

8,609

21.0'

18'

10,926

9,098

22.0'

19'

11,513

9,587

23.0'

20'

12,101

10,076

24.0'

21'

12,688

10,565

25.0'

22'

13,275

11,054

26.0'

23'

13,862

11,543

27.0'

24'

14,450

12,032

28.0'

25'

15,037

12,521

29.0'

26'

15,624

13,010

30.0'

27'

16,211

13,499

31.0'

28'

16,798

13,988

32.0'

29'

17,386

14,477

33.0'

30'

17,973

14,966

34.0'

11' Diameter

Height

US gal

Imp gal

Overall Height

3,316

2,716

8.3"

4,027

3,353

9.3'

6,158

5,128

12.3'

6,869

5,720

13.3'

10'

7,579

6,311

14.3'

12'

9,001

7,495

16.3'

13'

9,711

8,086

17.3'

14'

10,422

8,678

18.3'

15'

11,132

9,269

19.3'

16'

11,843

9,861

20.3'

17'

12,553

10,453

21.3'

18'

13,264

11,044

22.3'

19'

13,974

11,636

23.3'

20'

14,685

12,228

24.3'

21'

15,395

12,819

25.3'

22'

16,106

13,411

26.3'

23'

16,816

14,003

27.3'

24'

17,527

14,594

28.3'

25'

18,238

15,186

29.3'

26'

18,948

15,778

30.3'

27'

19,659

16,369

31.3'

28'

20,369

16,961

32.3'

29'

21,080

17,553

33.3'

30'

21,790

18,144

34.3'

12' Diameter

Height

US gal

Imp gal

Overall Height

3,998

3,329

8.5'

4,844

4,033

9.5'

7,380

6,145

12.5'

8,226

6,850

13.5'

10'

9,072

7,554

14.5'

12'

10,763

8,962

16.5'

13'

11,608

9,666

17.5'

14'

12,454

10,370

18.5'

15'

13,300

11,074

19.5'

16'

14,145

11,778

20.5'

17'

14,991

12,482

21.5'

18'

15,836

13,186

22.5'

19'

16,682

13,891

23.5'

20'

17,528

14,595

24.5'

21'

18,373

15,299

25.5'

22'

19,219

16,003

26.5'

23'

20,064

16,707

27.5'

24'

20,910

17,411

28.5'

25'

21,755

18,115

29.5'

26'

22,601

18,819

30.5'

27'

23,447

19,523

31.5'

28'

24,292

20,228

32.5'

29'

25,138

20,932

33.5'

30'

25,983

21,636

34.5'

CHEMICAL COMPATIBILITY TEST

See if our stainless steel chemical mixing tanks are suited for your operation by checking the Chemical Compatibility Database from Cole-Palmer. Be sure to select “Stainless Steel – 304” in the “Materials” dropdown list.

Check Compatibility

CUSTOM SIZES

We design and build tanks to meet your needs. If you require an alternate sized mixing tank that is not shown on our chart, contact us to get started!

CWB Division 2 Certified

There is no room for compromise with Novid Inc. chemical mixing tanks. Novid Inc. is CWB Division 2 certified, and understands the importance of using correct welding procedures and processes in order to deliver the best product. All Novid Inc. welders are trained and certified to weld stainless steel.
